Ferrule crimping tool PEW 8.84

Sideways insertion

• For crimping insulated and non-insulated ferrules according to DIN 46 228
• Self-adjusting adaptation to the required size of ferrule
• Ferrules are inserted sideways into the tool
• Force magnified by lever action to ensure fatigue-free working
• Precise, factory-set (calibrated) crimping pressure
• Consistent crimping quality with forced-lock completion of crimping process (can be released)
• 2 profiled/2 smooth crimp surfaces
• Black-oxide finish
• Specially hardened spring steel
• Ergonomic 2-component grips

Technical data

• Art. No.: 610 084 3 2
• EAN: 4049002018145
• Weight: 440 g
• Dimension: 176 x 77 x 23 mm
• Finish: black-oxide finish
• Number of crimping positions: 1
• Ferrules: 0.08 – 10.0 mm² / AWG 28 – 8
• Twin ferrules: 2x 0.25 – 6.0 mm² / 2x AWG 22 – 8
• Crimp surfaces: 2 profiled/2 smooth crimp surfaces
• Contact insertion: Sideways insertion
