Electric crimping machine

Crimping machine CM 25-3

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany
with ferrule crimping unit
SKU: 636 086 3
€9,386.67
Stock status: Out of stock
Indicative price
Description

with ferrule crimping unit

  • Compact, maintenance-free table-top device
  • Crimp force 25 kN, working pressure 6 bar
  • Air requirements 0.75 l/work stroke
  • Hand or foot operation
  • Height-adjustable feet
  • Crimp unit for insulated and uninsulated 0.08 mm² to 6 mm² ferrules
  • Automatic adjustment to cross-section when crimping insulated and non-insulated ferrules according to DIN 46 228
  • Hexagonal crimp profile with 6 profiled crimp surfaces
  • Adjustable insertion guide for insulated ferrules
  • Quick and simple retooling makes it suitable for short- and medium-run production

Technical data

  • Art. No.: 636 086 3
  • EAN: 4049002127465
  • Weight: 32,400 g
  • Dimension: 325 x 280 x 500 mm
  • Number of crimping positions: 1
  • Ferrules: 0.08 – 6.0 mm² / AWG 28 – 10
  • Twin ferrules: 2x 0.25 – 4.0 mm² / 2x AWG 22 – 12

Specifications

  • Trọng lượng: 32,400 g
  • Kích thước: 325 x 280 x 500 mm
  • Số vị trí ép: 1
  • Dải cos đơn: 0.08 – 6.0 mm² / AWG 28 – 10
  • Dải cos đôi: 2x 0.25 – 4.0 mm² / 2x AWG 22 – 12
  • Lực ép: 25 kN
  • Áp suất làm việc: 6 bar
  • Tiêu hao khí: 0.75 l/hành trình
  • Kiểu vận hành: Tay hoặc chân
  • Profile ép: Hexagonal 6 mặt
  • Tiêu chuẩn: DIN 46 228
  • Chân đế: Điều chỉnh độ cao
