Electric crimping machine

CM 25-3 crimping machine without crimping unit, without positioning guide

★ 0.0 (0 reviews)
Sold: 0
Views: 0
Imported from: Germany
Origin: Made in Germany
Compact, maintenance-free table-top device
SKU: 636 025-3
€7,869.84
Stock status: Out of stock
Indicative price
Description
  • Compact, maintenance-free table-top device
  • Hand or foot operation
  • Height-adjustable feet
  • Crimp force 25 kN, working pressure 6 bar
  • Air requirements 0.75 l/work stroke
  • Quick and simple retooling makes it suitable for short- and medium-run production
  • Various crimping units are available for processing turned pin and socket contacts
  • Positioning guides for industrial and aviation contacts can be attached in a similar way for use in hand tools
  • Base machine can also be used for crimping units for processing ferrules
  • Crimping units for insulated and non-insulated ferrules from 0.08 to 10 mm²

Technical data

  • Art. No.: 636 025-3
  • EAN: 4049002029561
  • Weight: 31,800 g
  • Dimension: 325 x 280 x 500 mm
Optional Accessories
SKU Image Price VNĐ Product name & short description
636 084 3 0 Ferrule Crimping Unit, Square Crimp
€1,546.51
Ferrule Crimping Unit, Square Crimp
Crimp unit for insulated and uninsulated 0.08 mm² to 10 mm² ferrules
636 086 3 0 Ferrule Crimping Unit, Hex Crimp
€1,546.51
Ferrule Crimping Unit, Hex Crimp
Crimp unit for insulated and uninsulated 0.08 mm² to 6 mm² ferrules
